| 1 |
** |
Burner Carriage ( No Longer Available ) |
| 2 |
110061-03 |
Front and Rear Burner Tube ( No Longer Available ) |
| 3 |
110061-01 |
Middle Burner Remote Tube ( No Longer Available ) |
| 4 |
111124-01 |
Retainer Spring ( No Longer Available ) |
| 5 |
110063-02 |
Burner, Front Blue Flame ( No Longer Available ) |
| 6 |
110063-01 |
Burner, Middle Blue Flame ( No Longer Available ) |
| 7 |
108105-02 |
Burner, Rear ( No Longer Available ) |
| 8 |
107110-01 |
Spacer ( No Longer Available ) |
| 9 |
PP225 |
ODS Pilot ( Use Replacment 103778-01 ) |
| 10 |
108135-01 |
Valve Bracket ( No Longer Available ) |
| 11 |
099387-09 |
Pilot Tube |
| 12 |
099387-15 |
Pilot Regulator Tube NG |
| 13 |
110093-07 |
Pilot Mounting Bracket ( No Longer Available ) |
| 14 |
097159-04 |
Piezo Igniter |
| 15 |
098271-10 |
Ignitor Cable |
| 16 |
099056-21 |
Burner Orifice Injector Back |
| 17 |
101004-18 |
Burner Orifice Injector Front ( No Longer Available ) |
| 18 |
101004-13 |
Burner Orifice Injector Middle ( No Longer Available ) |
| 19 |
108692-04CK |
Remote Cover Plate ( No Longer Available ) |
| 20 |
098265-02 |
Male Elbow |
| 21 |
M12461-26 |
Screw, Hex Slt Wsr 10-32 x 0.38 |
| 22 |
099918-02 |
Pilot Regulator, NG |
| 23 |
103781-04 |
Gas Control Valve ( Use Replacment 0820660 ) |
| 24 |
108106-01 |
Manual Control Valve ( No Longer Available ) |
| 25 |
099393-03 |
Control Knob ( No Longer Available ) |
| 26 |
098508-01 |
Valve Retainer Nut |
| 27 |
103284-03 |
Wire Harness |
| 28 |
108111-01 |
Cast Iron Grate ( No Longer Available ) |
| 29 |
103587-02 |
Plate, Switch ( No Longer Available ) |
| 30 |
099998-01 |
Fan Switch |
| 31 |
103784-01 |
On-Off-Pilot Knob Extension |
| 32 |
109631-01 |
Log Alignment Screw ( No Longer Available ) |
