| 1 |
|
Part Not Available for Field Replacement |
| 2 |
120785-01 |
Valve Bracket ( No Longer Available ) |
| 3 |
098522-12 |
Gas Valve Assembly NG
( Use Replacment 0630545 ) |
| 4 |
098867-19 |
Gas Regulator, NG ( No Longer Available ) |
| 5 |
097159-04 |
Piezo Ignitor |
| 6 |
120783-01 |
Cast Iron Grate ( No Longer Available ) |
| 7 |
120795-01 |
Inlet Tube ( No Longer Available ) |
| 8 |
120786-01 |
Burner NG ( No Longer Available ) |
| 9 |
121544-01 |
Outlet Tube ( No Longer Available ) |
| 10 |
M11084-26 |
HWH AB 10-16 x 0.38 Screw "
( No Longer Available ) |
| 11 |
099211-01 |
HWH AB 10-16 x 2.50 Screw " |
| 12 |
M11084-38 |
HWH AB 8-18 x 0.38 Screw " |
| 13 |
120630-01 |
ODS Pilot, NG |
| 14 |
098249-01 |
ODS Nut |
| 15 |
098271-10 |
Ignitor Cable |
| 16 |
099056-16 |
Injector, 0.1200 |
| 17 |
099387-09 |
Pilot Tube |
| 18 |
108134-02 |
NG Plate ( No Longer Available ) |
| 19 |
108188-02 |
Type U Drive 2 x 0.25 Screw " ( No Longer Available ) |
| 20 |
098544-01 |
Thermobulb/Clip |
| 21 |
099064-02 |
Nylon Spacer ( No Longer Available ) |
| 22 |
M11084-31 |
HWH AB 10-16 x 1.0 ( No Longer Available ) |
| 23 |
121606-01 |
Main Log ( No Longer Available ) |
| 24 |
121606-02 |
Front Log ( No Longer Available ) |
| 25 |
121606-03 |
Crossover Log ( No Longer Available ) |
| 26 |
099230-02 |
Shoulder Screw 10 x 0.63 " |
