| 1 |
104897-01 |
Middle Log (#1) ( No Longer Available ) |
| 1 |
104897-02 |
Middle Log (#1) ( No Longer Available ) |
| 2 |
104898-02 |
Back Log (#2) ( No Longer Available ) |
| 3 |
104899-02 |
Crossover Log (#3) ( No Longer Available ) |
| 4 |
104896-02 |
Front Log (#4) ( No Longer Available ) |
| 5 |
104900-02 |
Log Piece (#5) ( No Longer Available ) |
| 6 |
102844-01 |
Lower Bracket |
| 7 |
102966-01 |
Upper Bracket ( No Longer Available ) |
| 8 |
098867-14 |
Gas Regulator |
| 9 |
102981-01 |
Inlet Tube |
| 10 |
102983-01 |
Outlet Burner Tube ( No Longer Available ) |
| 11 |
099056-16 |
Burner Orifice Injector |
| 12 |
102843-01 |
Burner Clip |
| 13 |
102772-01 |
Burner |
| 14 |
101329-20 |
Thermostat Gas Valve Assembly ( Use Replacment 0630546 ) |
| 15 |
102979-01 |
Thermostat Bracket ( No Longer Available ) |
| 16 |
098544-01 |
Thermobulb Clip |
| 17 |
102445-01 |
Piezo Ignitor |
| 18 |
099387-09 |
Pilot Tube |
| 19 |
098271-07 |
Ignitor Cable ( No Longer Available ) |
| 20 |
104285-01 |
ODS Pilot |
| 21 |
M11084-38 |
Hex Screw, #8-18 x .38 |
| 22 |
098249-01 |
Nut, M5 |
| 23 |
099211-01 |
Hex Screw, 10-16 x 2.50 |
| 24 |
102775-07CK |
Painted Base Assembly ( No Longer Available ) |
