| 1 |
098304-01 |
Screw #10 x 3/8" |
| 2 |
098742-03 |
Front Panel ( No Longer Available ) |
| 3 |
098197-01 |
Grill Guard ( No Longer Available ) |
| 4 |
098342-01 |
Clip Grill Guard ( No Longer Available ) |
| 5 |
098533-01BR |
Botton Glass Retainer ( No Longer Available ) |
| 6 |
098260-01 |
Glass Panel ( No Longer Available ) |
| 7 |
098532-01BR |
Top Glass Retainer ( No Longer Available ) |
| 8 |
M11084-26 | Screw #10 x 3/8" ( No Longer Available ) |
| 9 |
098352-01BR |
Deflector Unit ( No Longer Available ) |
| 10 |
098271-02 |
Ignitor Cable ( No Longer Available ) |
| 11 |
098249-01 |
Nut, M5 |
| 12 |
098244-01 |
ODS Pilot Assembly ( No Longer Available ) |
| 12-1 |
098514-01 |
Thermocouple |
| 12-2 |
098515-01 |
Ignitor Electrode ( No Longer Available ) |
| 13 |
098242-01 |
Burner ( No Longer Available ) |
| 14 |
098517-01 |
3/16" Pilot Tubing( No Longer Available ) |
| 15 |
098251-02 |
Injector |
| 16 |
098250-01 |
Injector Holder |
| 17 |
098924-01 |
Pressure Regulator Kit ( No Longer Available ) |
| 18 |
098274-01 |
1/2" NPT Male Connector ( No Longer Available ) |
| 19 |
098519-01 |
3/8" Outlet ( Burner) Tubing ( No Longer Available ) |
| 20 |
098521-01 |
3/8" Inlet Tubing ( No Longer Available ) |
| 21 |
* |
3/8" NPT Male Connector |
| 22 |
* |
1/8" NPT Plug |
| 23 |
* |
38" to 1/8" NPT Bushing |
| 24 |
098265-01 |
3/8" NPT Male Elbow ( No Longer Available ) |
| 25 |
* |
3/8" NPT Plug |
| 26 |
098246-02 |
Control Valve |
| 27 |
098529-01 |
Cabinet ( No Longer Available ) |
| 28 |
097159-01 |
Piezo Ignitor( No Longer Available ) |
| 29 |
* |
Fastener, "U" Nut |
| 30 |
M11084-26 | Screw #10 x 3/8" ( No Longer Available ) |
| 31 |
M11084-38 |
Screw #8 x 3/8" |
| 32 |
099066-01 |
Mounting Bracket ( No Longer Available ) |
| 33 |
098268-01 |
1/2" NPT Female Elbow ( No Longer Available ) |
| 34 |
098354-01 |
Control Knob |
| 35 |
098508-01 |
Valve Retainer Nut |
