1 | 10767-03 | Front Panel ( No Longer Available ) |
2 | 10476-01 | Grill Guard ( No Longer Available ) |
3 | ** | Apron |
4 | 107894-1 | Reflector Assembly ( No Longer Available ) |
5 | ** | Cabinet Back Panel |
6 | 097159-04 | Piezo Ignitor |
7 | 099066-02 | Mounting Bracket ( No Longer Available ) |
8 | 09871-09 | Ignitor Cable ( No Longer Available ) |
9 | 09846-01 | Control Rod Assembly ( No Longer Available ) |
10 | 098325-01 | Roll Pin |
11 | 098354-03 | Control Knob ( No Longer Available ) |
12 | 099415-19 | Gas Regulator Natural Gas |
13 | 104819-02 | Regulator Bracket ( No Longer Available ) |
14 | 119099-01 | Lower Baffle ( No Longer Available ) |
15 | 09908-01 | Strain Relief Bushing ( Included with Fan Kit ) |
16 | 103256-02 | Inlet Tube ( No Longer Available ) |
17 | 109303-04 | Upper Baffle ( Included with Fan Kit ) |
18 | 118661-01 | Housing Duct ( Included with Fan Kit ) |
19 | M50104-03 |
Shorty Bushing ( Included with Fan Kit ) |
20 | 119283-01 | Fan Kit ( No Longer Available ) |
21 | 098522-25 | Thermostat Gas Valve |
22 | 102394-02 |
Thermostat Valve Mounting Bracket ( Use Replacement 102394-02SA ) |
23 | 119664-01 | Thermal Limit Switch |
